Pump 1 HP Chemical Dosing Pedrollo Italy AL-RED 1Phase

Description
As a result of their construction characteristics, these centrifugal pumps are suitable for use in the domestic, agricultural and industrial sectors. All of the components in contact with the pumped liquid are constructed from stainless steel AISI 304, thus guaranteeing complete hygiene and maximum resistance against corrosion.
Suitable for use with clean water and liquids that are not chemically aggressive towards the materials from which the pump is made.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.

Features
Liquid type: Clean Water

Uses: domestic, industrial, agriculture

Applications: water supply systems, air conditioning systems, washing systems, cooling systems, water treatment plants, irrigation pumps

typology: surface

Family: centrifugal

Performance Range:

Flow rate up to 160 l/min (9,6 m³/h)
Head up to 23 m
Application Limit:

Temperature of the liquid from -10 °C to +90 °C
Ambient Temperature da -10 °C to +40 °C
Manometric suction lift up to 7 m
Max. working pressure 4 bar
Continuous service S1
